Model No.: MC14LC5480DWR2

Production Capacity: 10000pcs/month

Delivery Date: IN STOCK

Type: Others

Supply Voltage: Email us

Operating Temperature: Email us

Means of Transport: Air

Packing: SOIC20

Application: Others

Brand Name: Freescale Semiconductor, In...

Dissipation Power: john(at)eis-ic.com

john(at)eis-ic.com: john(at)eis-ic.com

On-Chip Precision Reference Voltage 1.575V, SOIC20, 5 V PCM Codec-Filter, general purpose

Company Name: Excellent Integrated System LIMITED

Contact Person : John

Email/Msn :John(at)eis-ic.com

Tel : 00852-30777742

Add.: RM 906, WORKINGBERG COMM BLDG, 41-47 MARBLE RD, HONGKONG

Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question,please email us: john(at)eis-ic.com.

PART NUMBER	MC14LC5480DWR2
BRAND	Freescale Semiconductor, Inc [Freescale]
PACKAGING	SOIC20
DATE CODE	2010+ROHS!
PRICE	0.5~1.8USD
Summary	On-Chip Precision Reference Voltage 1.575V, SOIC20, 5 V PCM Codec-Filter, general purpose

Description as follow:

The MC14LC5480DWR2 is a general purpose per channel PCM Codec-Filter with pin selectable Mu-Law or A-Law companding, and is offered in 20-pin DIP, SOG, and SSOP packages. The MC14LC5480DWR2 performs the voice digitization and reconstruction as well as the band limiting and smoothing required for PCM systems. The MC14LC5480DWR2 is designed to operate in both synchronous and asynchronous applications and contains an on-chip precision reference voltage.

Parametrics

MC14LC5480DWR2 absolute maximum ratings: (1)DC Supply Voltage:-0.5V to 6V; (2)Voltage on Any Analog Input or Output Pin:VSS-0.3V to VDD+0.3V; (3)Voltage on Any Digital Input or Output Pin:VSS-0.3V to VDD+0.3V; (4)Operating Temperature Range:-40℃ to + 85℃; (5)Storage Temperature Range:-85℃ to +150℃.

Features

MC14LC5480DWR2 features: (1)Pin for Pin Replacement for the MC145480; (2)Single 5 V Power Supply; (3)Typical Power Dissipation of 15 mW, Power-Down of 0.01 mW; (4)Fully-Differential Analog Circuit Design for Lowest Noise; (5)Transmit Band-Pass and Receive Low-Pass Filters On-Chip; (6)Active R-C Pre-Filtering and Post-Filtering; (7)Mu-Law and A-Law Companding by Pin Selection; (8)On-Chip Precision Reference Voltage (1.575 V); (9)Push-Pull 300Ω Power Drivers with External Gain Adjust; (10)MC145536EVK is the Evaluation Kit that Also Includes the MC145532 ADPCM Transcoder.

Diagrams
